Product Description
Type 111
Applications:
Used for pneumatic systems
Compressors,compressed air system
Suitable for fluid medium which does not clog connection port or corrode copper alloy．
Case：black steel (black painting steel,chromed steel,ABS)
Ring：no (black steel,black painting steel,chromed steel)
Window：acrylic (glass,acrylic,polycarbonate)
Socket & Connection：brass
Movement：semi-brass (complete brass)
Bourdon tube：copper alloy (brass)
Pointer and dial：aluminum
Range：vacuum,compound 0 to 6000 psi accuracy
Class：F±3/2/3%(ASME B40.100 Grade B)
Kl 2.5 FOR 1 1/2″,2″,Kl 1.6 FOR 2 1/2″,3″,4″
Ambient：-40 °F to 140 °F (-40℃ TO 60℃)
Media：140 °F (+60℃) Maximum
